ACTI9 ICT 63A 4P 24V AC connector, remote control, IP20, DIN rail mounting

The Acti9 iCT 63A 4NC 24Vac is a connector from the ICT range, designed for lighting, heating, and motor applications. This device, part of the renowned Acti9 range, offers an efficient and reliable solution for controlling electrical circuits in residential and small commercial environments.

With 4 NC poles and a rated operating current of 63 A in AC-7A and 20 A in AC-7B, the iCT ensures optimal performance under various operating conditions.

Technical features include:

• Main frequency: 50 Hz
• Nominal operating voltage: 400 V AC at 50 Hz
• Maximum power: 2.1 W at 400 V AC
• Mechanical durability: 1,000,000 cycles
• Electrical durability: 100,000 cycles at 63 A and 30,000 cycles at 20 A
• Adjustable clip mounting on 35 mm DIN rail
• Protection rating: IP20
• Operating ambient temperature: -5 to 60 °C
• Relative humidity: 95% to 55% °C
• Maximum operating altitude: 2000 m

The Acti9 iCT combines robustness and versatility, making it an ideal choice for those seeking a high-performance and durable connector for their electrical installations.
