HAGER MUN510A | Circuit breaker 1P+N 10A curve-C 6kA

HAGER MUN510A | Circuit breaker 1P+N 10A curve-C 6kA

HAGER MUN510A | Circuit breaker 1P+N 10A curve-C 6kA

HAGER MUN510A | Circuit breaker 1P+N 10A curve-C 6kA

HAGER MUN510A | Circuit breaker 1P+N 10A curve-C 6kA

Reference HAGER MUN510A

Available

€10.54

VAT included

1P+N magneto-thermal automatic switch with a nominal current of 10A. This curve C accessory has a voltage of 230/400V AC 50/60Hz and a breaking capacity of 6kA. Thus, the switch with a tightening torque of 2.8Nm has dimensions of 83x35x70mm. This device is characterized by maintaining the IP20 protection degree and an operating temperature of -25 to 60°C. In addition, the MU series offers a variety of products with innovative and timeless designs focused on functionality. Likewise, the range offers the switch with different technical characteristics.

In stock 887 Items

Email address

Product Details

Rated current (A): 10
Curve: C
EAN: 3250614316678
Manufacturer: HAGER
No. of poles: 1P+N
Weight (kg): 0
Reference: HAGER MUN510A
Safety warning: No
GPSR Safety warning: No
GPSR Manufacturer information: HAGER / France / 132 Boulevard d'Europe, 67215 Obernai, France / [email protected] / +33 388495050
GPSR EU responsible person: HAGER / France / 132 Boulevard d'Europe, 67215 Obernai, France / [email protected] / +33 388495050
GPSR e-mail manufacturer: [email protected]

In stock 887 Items

Reviews (0)

No reviews
