Pulsador iPB 1NO-1NC doble ver
Pulsador iPB 1NO-1NC doble ver

ACTI 9 IPB 1NO-1NC 20A 250V AC push button, DIN rail mounting 35mm

IMPO A9E18034
Available
€22.82
VAT included
Acti 9 iPB 1NO-1NC double pushbutton, designed for DIN rail mounting. With 1 NC and 1 NO contacts, it supports 20 A and 250 V AC. Ideal for small shops and residential environments. Complies with IEC 60947-5-1 and IEC 60669-1 standards.
10 Items

Description

The iPB 1NO-1NC double pushbutton from the Acti 9 range is a device designed to offer efficient and safe control in residential and small commercial applications. This pushbutton, belonging to the IPB range, complies with IEC 60947-5-1 and IEC 60669-1 standards, guaranteeing its reliability and durability under various operating conditions.

With a compact design, the iPB features fixed mounting on a symmetrical 35 mm DIN rail, facilitating its integration into electrical systems. Its structure includes two types of contacts: one normally closed (NC) and one normally open (NO), with a rated operating current of 20 A and a rated voltage of 250 V AC.

This push button is equipped with a two-button control in green and red, allowing for clear identification of its status. Among its technical characteristics are: Electrical durability: 30,000 AC cycles 50/60 Hz (AC-22, state 1) Operating ambient temperature: -35…70 °C Storage ambient temperature: -40…80 °C Relative humidity: 95% at 55 °C Connections: stepped terminals for rigid and flexible cables up to 2.5 mm² Stripped cable length for connecting terminals: 9 mm Tightening torque: 1 Nm Color: White Height: 82 mm, Width: 18 mm Depth: 71.5 mm
  • Compatibility code: IPB

    • Product Details

    EAN
    3606480088261
    Manufacturer
    SCHNEIDER
    Reference
    SCHNEIDER A9E18034
    GPSR Safety warning
    No
    GPSR Manufacturer information
    Schneider Electric España, S.A. / Spain / Calle Bac de Roda, 52 - Edificio A, 08019 Barcelona / [email protected] / +34 930289900
    GPSR EU responsible person
    Schneider Electric España, S.A. / Spain / Calle Bac de Roda, 52 - Edificio A, 08019 Barcelona / [email protected] / +34 930289900
    GPSR e-mail manufacturer
    [email protected]
