STB 24V DC 2A Solid State Digital Output Kit with 2 Outputs and IP20 Protection

The STB, Std, 02 SD TRT, 24VDC 2A Kit_STBXTS is a distributed I/O solution from the Modicon STB range, designed for industrial applications requiring highly reliable digital outputs. This kit includes an STBXBA1000 base and connection modules that facilitate integration into automated systems. With an STBDDO3230 module providing two solid-state digital outputs, this kit operates at 24VDC, ensuring optimal performance in demanding environments.

The STB, Std, 02 SD TRT is characterized by its robustness and versatility, allowing for positive or negative logic configurations. Its design includes protection against thermal overload, short circuits, and reverse polarity, ensuring system integrity.

• Number of digital outputs: 2
• Output type: Solid state
• Output voltage: 24 V DC
• Response time: 520 µs off-to-on, 720 µs on-to-off
• Protection: Short circuits, thermal overload, reverse polarity
• Standards: IEC 61131-2, NF, CSA, UL
• Protection rating: IP20
• Operating temperature: 0…60 °C
• Relative humidity: 95% at 60 °C without condensation
• Weight: 0.116 kg
