COMPACT 160A 4P TMD 90kA 690V AC IP40 Circuit Breaker

The NSXm160N 50kA AC 4P4R 160A TMD ELINK circuit breaker from the New Generation ComPacT range is an advanced solution for protecting electrical circuits in applications with currents above 0.1 A. Designed to operate in alternating current (AC) networks with a nominal voltage up to 690 V and a nominal current of 160 A at 40 °C, this device stands out for its breaking capacity of 90 kA at 220–240 V and 50 kA at 380–440 V, ensuring robust and reliable protection.

The NSXm 160N features four poles (4P) and four protected poles (4R), with the neutral position on the left. Its thermal-magnetic tripping technology and TM-D control unit enable a fast response to overloads and short circuits. This circuit breaker is suitable for a wide range of industrial applications, meeting Category A and offering a breaking capacity in accordance with EN> 50 A.

• Mechanical durability: 20,000 cycles
• Electrical durability: 10,000 cycles at 440 V
• Operating temperature: -25 to 70 °C
• Protection rating: IP40
• Surge withstand capacity: 8 kV
• Connections: 2.5 to 95 mm² terminals
• Dimensions: 108 mm (width) x 137 mm (height) x 80 mm (depth)
• Weight: 1.42 kg
• Color: Gray (RAL 7016)
• Contamination rating: 3
