Modicon M340 Processor Module 1024 Digital I/Os

Available

Industrial automation

Modicon M340 Processor Module 1024 Digital I/Os

IMPO BMXP342020

Module processor of the Modicon M340 platform with capacity for 1024 digital I/O and 256 analog I/O in multi-track configuration. Supports Ethernet communication TCP/IP, Modbus RTU/ASCII and RS232C/RS485 series links. Includes 36 specific application channels and bandwidth management.

Modicon M340 512 Digital I/O Processor Module

Available

Industrial automation

Modicon M340 512 Digital I/O Processor Module

IMPO BMXP341000

€525.87

Module processor of the Modicon M340 platform, with capacity for up to 512 digital inputs/outputs and 128 analogs in multitrack configuration. Supports RJ45 series communication (RS232C/RS485) and USB at 12 Mbit/s. Includes 20 specific application channels, 2048 kB internal RAM and Modbus RTU/ASCII compatibility.

Modicon M340 Ethernet RS485 Communication Module

Available

Industrial automation

Modicon M340 Ethernet RS485 Communication Module

IMPO BMXNOR0200H

€1,428.88

Communication module for the Modicon M340 platform, compatible with IEC 60870-5-101/104, DNP3 and Modbus TCP protocols. It has Ethernet ports RJ45 10/100 Mbit/s and RS232/485 series. It supports multiple protocols in a single module (teacher and slave), time-marked event management and data storage on 128 MB SD card.

Standard RS232/485 serial connection module

Available

Industrial automation

Standard RS232/485 serial connection module

IMPO BMXNOM0200

€702.86

Series communication module for the Modicon X80 range, with two integrated interfaces: RS232 (115.2 kbit/s, 8 threads) and RS485 (57.6 kbit/s, 1 pair braided). Internal power supply from rack, consumption of 80 mA to 24 V DC.

Ethernet module TCP/IP Modicon M340 10/100 Mbit/s 1 class C30 port

Available

Industrial automation

Ethernet module TCP/IP Modicon M340 10/100 Mbit/s 1 class C30 port

IMPO BMXNOE0110

€1,213.98

TCP/IP Ethernet network module for the Modicon M340 platform, with RJ45 10/100 Mbit/s connection, C30 class and Transparent Ready compatibility. Includes 16 MB internal flash memory and support for SOAP/XML, SNMP and Modbus web services. Internal power from rack, consumption of 90 mA to 24 V DC.

Ethernet module TCP/IP Modicon M340 10/100 Mbit/s 1 B30 class port

Available

Industrial automation

Ethernet module TCP/IP Modicon M340 10/100 Mbit/s 1 B30 class port

IMPO BMXNOE0100

€1,065.93

TCP/IP Ethernet network module for the Modicon M340 platform, with RJ45 10/100 Mbit/s connection, Modbus support and TCP messaging, integrated Flash memory BMXRWSC016M, internal rack power, IP20 protection degree and operation in 0 to 60 °C environments.

Ethernet module TCP/IP Modicon M340 10/100 Mbit/s 4 ports

Available

Industrial automation

Ethernet module TCP/IP Modicon M340 10/100 Mbit/s 4 ports

IMPO BMXNOC0401

€1,329.34

TCP/IP Ethernet network module for Modicon M340 platform, with RJ45 10/100 Mbit/s connection, RSTP support, integrated 4-port switch, compatible with Ethernet/IP and SNMP, IP20 protection grade, operating between 0 and 60 °C, internal rack power, CE certificate, UL, CSA and ATEX zone 2/22.

20P Terminal Block with 3 m Pre-wired Cable

Available

Industrial automation

20P Terminal Block with 3 m Pre-wired Cable

IMPO BMXFTW301

€49.96

20-way connector with 3 m pre-formed cable for Modicon X80 I/O modules. Includes removable terminals with color coding according to DIN 47100. Cable cross-section 0,324 mm², 20 consecutive wires, designed for quick installation and secure connection in industrial environments.

Available

Industrial automation

28P spring terminal for Modicon X80

IMPO BMXFTB2820

€31.92

Removable connection block for Modicon X80 modules, with 28 spring type terminals. Designed for quick installation and disassembly without tools. Compatible with 28 pin modules. Weight: 0.07 kg. It meets EU RoHS proactive compliance requirements, without toxic heavy metals or mercury.

Available

Industrial automation

Terminal block 28P screw Modicon X80

IMPO BMXFTB2800

€31.38

Removable connection block for Modicon X80 modules with 28 gaiola terminals. Designed for industrial installations where secure and fast connection is required. Compatible with 28 pin modules. Weight: 0.111 kg. It complies with proactive compliance RoHS EU, without toxic heavy metals or mercury.

Terminal block 20P with removable spring Modicon X80

Available

Industrial automation

Terminal block 20P with removable spring Modicon X80

IMPO BMXFTB2020

€28.66

Removable connection block for Modicon X80 modules, with 20 spring type terminals. Designed for quick installation and disassembly without tools. It complies with proactive compliance with the EU RoHS directive, without mercury or toxic heavy metals. Compatible exclusively with modules that require 20 pin removable terminal block.

20P screw-terminal terminal block for Modicon X80

Available

Industrial automation

20P screw-terminal terminal block for Modicon X80

IMPO BMXFTB2010

€31.50

Removable connector for Modicon X80 modules, with 20 screw-stribe terminals. Designed for installation and rapid dismantling in industrial automation systems. It supports currents up to 10 A per terminal. Manufactured without toxic heavy metals or mercury, complying with EU RoHS exemptions. Weight: 0.075 kg.
