SCHNEIDER 63A 4P 15000A 415V Type C Miniature Circuit Breaker

The Dardo Plus C120H miniature circuit breaker, part of the Acti 9 series, is an advanced solution for protecting electrical circuits in residential and small commercial applications. Designed to handle currents above 0.1 A, this device features four poles (4P) and a rated current of 63 A at 30 °C, ensuring optimal performance in alternating current (AC) networks.

The C120H utilizes thermal-magnetic tripping technology, enabling it to offer an exceptional breaking capacity of up to 15,000 A under specific conditions, complying with EN/IEC 60898-1 standards. Its design includes a contact position indicator and local signaling for easy identification of the device's status.

This circuit breaker is compatible with 35 mm symmetrical DIN rail mounting and features a mechanical durability of 20,000 cycles and an electrical durability of 10,000 cycles.

• Rated current: 63 A at 30 °C
• Number of poles: 4P
• Breaking capacity: 15,000 A Icn
• Rated operating voltage: 380...415 V AC
• Main frequency: 50/60 Hz
• Mechanical durability: 20,000 cycles
• Electrical durability: 10,000 cycles
• Protection rating: IP20
• Mounting: Symmetrical 35 mm DIN rail
• Weight: 0.82 kg
