Differential switch TX3 4/25/30 alternating current

The TX3 4/25/30 RCD is a 230 V~ four-pole automatic switch with 30 mA sensitivity and a 40A nominal current. It is part of the TX3 family of differential switches, which range from 25A to 40A and are all AC type, detecting AC component failures. In accordance with the UNE EN 61008-1 standard, they allow feeding by combs and have a built-in label holder. They do not accept auxiliaries and have a terminal capacity of 25 mm² flexible/35 mm² rigid.

• 30 mA sensitivity and 40A nominal current
• Alternating current operation (Type AC)
• Designed as a 4-module four-pole differential switch
• Complies with the UNE EN 61008-1 standard
• Allows feeding by combs
• With terminal connection capacity of 25 mm² flexible/35 mm² rigid
• Includes a built-in label holder for easy identification
• Does not accept auxiliaries
• Ideal for the protection of electrical circuits and equipment against leakage currents.
