Acti9 iC60N 4P 32 A C Curve Magnetic Thermal Switch

Miniature magnetic thermal switch from the Acti9 iC60N range, designed to protect electrical circuits in industrial and commercial installations. Features 4 protected poles and a rated current of 32 A, with a C curve to withstand initial current peaks without tripping.

Technical Features

• Number of poles: 4P
• Number of protected poles: 4
• Rated current [In]: 32 A
• Trip curve: C
• Tripping unit technology: Thermal-magnetic
• Breaking capacity Icn: 6000 A at 400 V AC 50/60 Hz
• Service breaking capacity [Ics]: 6000 A 100% at 400 V AC 50/60 Hz
• Limitation class: 3
• Rated operating voltage [Ue]: 220...240 V AC, 400 V AC, 380...415 V AC, 440 V AC, 125...180 V DC, 180...250 V AC
• Rated insulation voltage [Ui]: 500 V AC
• Surge voltage withstand [Uimp]: 6 kV
• Contact position indicator: Yes
• Local indications: Trip indicator
• Mounting support: DIN rail
• Protection degree: IP20
• Contamination degree: 3
• Overvoltage category: IV
• Operating ambient temperature: -35…70 °C
• Maximum operating altitude: 0...2000 m
• Connections: Single terminal, 1…35 mm² rigid, 1…25 mm² flexible
• Tightening torque: 3.5 N·m
• Stripped cable length: 14 mm
• Mechanical durability: 20000 cycles
• Electrical durability: 10000 cycles
• Color: White
• Weight: 0.5 kg
• Standards: EN 60898-1, IEC 60898-1, HB1, En> 50 A
• Quality labels: NF
• Green Premium product
• Compliant with EU RoHS, mercury-free, halogen-free
