Automatic switch NSX 100A SCHNEIDER ELINK 4P 16kA 440V AC IP40

The NSXm100E 16kA AC 4P 100A 4.1 ELINK earth leakage circuit breaker is part of the new generation ComPacT range, designed to provide reliable and efficient protection in applications with currents above 0.1 A. This device, belonging to the Compact NS KIT range, has four poles (4P) and a neutral position on the left, making it ideal for various electrical configurations.

With a rated current of 100 A at 40 °C and a rated operating voltage of 440 V AC at 50/60 Hz frequencies, the NSXm100E ensures high performance under demanding conditions. Its breaking capacity is remarkable, reaching up to 25 kA Icu at 220-240 V and 16 kA Icu at 380-415 V, ensuring robust protection against overloads and short circuits.

This circuit breaker is equipped with a Micrologic 4.2 control unit and electronic trip technology, offering advanced protection features such as LSoIR.

• Mechanical durability: 20,000 cycles
• Electrical durability: 10,000 cycles at 440 V In
• Protection rating: IP40
• Operating temperature: -25…70 °C
• Surge withstand voltage: 8 kV
• Leakage protection class: Class A and AC
• Adjustable leakage sensitivity: 30 mA to 5 A
• Dimensions: 108 mm x 144 mm x 80 mm
• Weight: 1.63 kg
• Color: Gray (RAL 7016)
