High frequency concealed ceiling detector

DINUY DM HF1 000
Available
€101.71
VAT included

• Motion Detector, with High Frequency technology (radar), for concealed installation.
• Detection is possible through doors, glass, false ceilings, walls…
• Timing, Light Level and Sensitivity adjustable by DIPs.
• Maximum coverage of 360º and Ø8m, at 2.5m height and 20ºC ~ 25ºC.
• Valid for all types of lamps, including LEDs and Fluorescence.
• Application examples: public toilets, elevators, etc.

5 Items

Notify me when in stock

Drop your email and we'll let you know the moment it's back.

Description

Product reference DM HF1 000
Supply Voltage (V) 230VAC
Frequency (Hz) 50/60
Own Consumption < 0.5W
Output Channels 1
Relay breaking power (A) 4
LED lamps (W) 200
Incandescent and Halogen 230V (W) 800
12V halogen lamps with electronic transformer (W) 400
Halogen lamps with ferromagnetic transformer (W) 400
Maximum number of devices 0
Voltage-free contact No
Detection angle (º) 360
Mounting height (m) 2.5
Detection diameter (m) 8
Maximum number of extra motion sensors 0
Minimum time delay (seconds) 5
Maximum time delay (minutes ) 15
Brightness level (lux) (min) 2
Brightness level (lux) (max) 50
HIGH FREQUENCY Technology (HF)
Concealed Mounting
Fluorescent Lamps (VA) 200
Contactor allowed Yes
Zero crossing Yes
Operating Temperature (ºC) (min) -20
Operating Temperature (ºC) (max) 60
Environmental Protection IP20, Class II

Product Details

EAN 8422447014600
Manufacturer Dinuy
Reference DINUY DM HF1 000
EAN 8422447014600
Manufacturer Dinuy
Reference DINUY DM HF1 000
5 Items

Reviews (0)

No reviews

GPSR

Fabricante Dinuy S. A.
Dirección postal Auzolan Kalea, 2, 20303 Irun, Gipuzkoa
Contacto electrónico [email protected]
Teléfono +34 943627988
Referencia DINUY DM HF1 000
EAN 8422447014600
