Comb bipolar connection 12 modules Schneider A9XPH212
Comb bipolar connection 12 modules Schneider A9XPH212

Bipolar comb connection 12 Schneider modules A9XPH212

IMPO A9XPH212
Available
€16.53
VAT included

Total Nº of modules of 18mm: 12

100 Items

Order now and receive it...

04-05-2026  with  MRW

between 04-05-2026 and 05-05-2026  with  Correos

Description

Number of addresses, 6-way N + 1 L

Poles configuration for 1-way 1 screw : 1P + N

1 screw : 2P

Step interpolate 18 mm

Connector type Tooth

Distance between way to 36 mm

With marking N L

Isolation Isolated

Presentation of the device is Trimmed

[Ie] rated Current of employment 100 A ( 40 °C )

[Ue] rated voltage of employment 415 V AC

[Ui] rated insulation Voltage 500 V AC according to IEC 61439-2

Mounting type Horizontal

Mounting location Top or bottom terminals-type tunnel

Top or bottom on dual terminal

Steps of 9 mm 24

Width 220 mm

White colour ( RAL 9003 )

Product Details

Reference
SCHNEIDER A9XPH212
Safety warning
No
GPSR Safety warning
No
GPSR Manufacturer information
Schneider Electric España, S.A. / Spain / Calle Bac de Roda, 52 - Edificio A, 08019 Barcelona / [email protected] / +34 930289900
GPSR EU responsible person
Schneider Electric España, S.A. / Spain / Calle Bac de Roda, 52 - Edificio A, 08019 Barcelona / [email protected] / +34 930289900
GPSR e-mail manufacturer
[email protected]
