STB,Bas,16 ED,24vDC Kit_STBXTS_Tornillo

STB,Bas,16 ED,24vDC Kit_STBXTS_Tornillo

SCHNEIDER STB Basic Digital Input Kit, 16 Inputs, 24V DC, IP20 Protection

Reference IMPO STBDDI3725KS

Out of stock

€303.01

VAT included

Modicon STB Basic Digital Input Kit, consisting of the STBDDI3725 module and STBXBA3000 base. It offers 16 digital inputs at 24 V DC, with reverse polarity protection and 1500 V isolation. Dimensions: 125 x 18.4 x 65.1 mm.

Email address

Description

The STB,Bas,16 ED,24vDC Kit_STBXTS_Screw is a basic digital input solution from the Modicon STB range, designed for industrial applications requiring precise and efficient control. This kit includes the STBDDI3725 module, the STBXBA3000 base, and an 18-pin screw connector (STBXTS1180), allowing the connection of up to 16 digital inputs with a 24 V DC voltage. Key features include: Number of digital inputs: 16; Digital input voltage: 24 V DC; Discrete input current: 4.5 mA; Response time: 2 ms (off-to-on and on-to-off); Protection: Integrated fuse, limiting resistor, and reverse polarity protection; Isolation: 1500 V between channels and logic bus.

Operating temperature: -25 to 70 °C

Protection rating: IP20

Standards: Complies with EN/IEC 61131-2 type 3

Weight: 0.086 kg

This kit is ideal for demanding industrial environments, guaranteeing reliable performance and easy integration into automation systems.

Product Details

EAN: 3595863932973
Manufacturer: SCHNEIDER
Reference: SCHNEIDER STBDDI3725KS
GPSR Safety warning: No
GPSR Manufacturer information: Schneider Electric España, S.A. / Spain / Calle Bac de Roda, 52 - Edificio A, 08019 Barcelona / [email protected] / +34 930289900
GPSR EU responsible person: Schneider Electric España, S.A. / Spain / Calle Bac de Roda, 52 - Edificio A, 08019 Barcelona / [email protected] / +34 930289900
GPSR e-mail manufacturer: [email protected]
