INT.AUT LEGRAND TX3 2P 32A C 6000A ACC

Circuit breaker TX3 6kA-C 2P 32A

INT.AUT LEGRAND TX3 2P 32A C 6000A ACC

Circuit breaker TX3 6kA-C 2P 32A

Circuit breaker TX3 6kA-C 2P 32A

Reference LEGRAND 403609

Available

€24.16

VAT included

The TX3 6KA-C circuit breaker is a two-pole 32A circuit breaker, which complies with the UNE EN-60898-1 standard and is designed for use in low voltage electrical installations.

Technical characteristics:

230/400 V~ bipolar magnetothermic automatic switch.
Tripping curve C.
Cutting power of 6000A.
Connection with terminals protected against direct contact (IP20).
Captive screws for easy installation.
Incorporated label holder for easy identification.
Terminalization capacity of up to 25 mm² flexible and 35 mm² rigid.
They can be equipped with motorized controls and DX³ control and signaling auxiliaries.
Automatic switches of the TX³ series available for nominal currents from 6A to 40A.

In stock 180 Items

Email address

Product Details

High: 77,8
Width: 35,4
Curve: C
EAN: 3245064036092
Manufacturer: LEGRAND
Intensity: 32
# Elements: 2
No. of poles: 2P
Weight (kg): 0
Protection: IP20
Reference: LEGRAND 403609
Safety warning: No
GPSR Safety warning: No
GPSR Manufacturer information: LEGRAND GROUP ESPAÑA, S.L. / Spain / C/ Hierro 56 – 28850 Torrejón de Ardoz (Madrid) / [email protected] / +34 916561812
GPSR EU responsible person: LEGRAND GROUP ESPAÑA, S.L. / Spain / C/ Hierro 56 – 28850 Torrejón de Ardoz (Madrid) / [email protected] / +34 916561812
GPSR e-mail manufacturer: [email protected]

In stock 180 Items
